Description
Dual fan pro flow radiator kits from Top Street Performance combine our best cooling components in one package. Included is an aluminum radiator, fan shroud, and a pair of high-flow fans.
ALUMINUM RADIATOR
Using intelligent design choices, TSP's radiators have a great deal to offer. Their aluminum construction is completely TIG welded and use no epoxy, meaning you can be sure of their durability. They feature a crossflow design with two rows of 1" aluminum tubes, surrounded by 17 fins per inch for maximum cooling.
CUSTOM FAN SHROUD
TSP’s aluminum fan shroud is designed to concentrate airflow to your cooling fan. Composed of high-quality aluminum, it fits perfectly with a TSP universal radiator. It also comes complete with rubber flaps for higher speeds when airflow through the grill increases.
PRO FLOW COOLING FANS
TSP's Pro Flow universal fans are designed for maximum airflow, featuring heavy duty motors and a deep shroud design. Like our other fans, they feature computer-balanced blades, and high-quality construction. A pair of Pro Flow fans will provide more than enough airflow to keep your engine cool.
SPECIFICATIONS
RADIATOR STYLE Crossflow
RADIATOR MATERIAL Aluminum
RADIATOR FINISH Natural
RADIATOR TUBE SIZE 1"
RADIATOR ROW QUANTITY 2
RADIATOR FIN DENSITY 17 fins / 1 in2
INLET LOCATION Upper Driver Side
RADIATOR INLET SIZE 1 1/2"
RADIATOR OUTLET LOCATION Lower Passenger Side
RADIATOR OUTLET SIZE 1 3/4"
RADIATOR CAP INCLUDED No
PETCOCK INCLUDED Yes
SHROUD INSTALLATION Bolt-on
FLAPS INCLUDED Yes
SHROUD MATERIAL Aluminum
SHROUD THICKNESS 1/16"
FAN QUANTITY 2
FAN DIAMETER 11"
FAN DEPTH 3 3/4"
FAN MATERIAL Heavy Duty Plastic
FAN BLADE STYLE Straight
FAN BLADE QUANTITY 5
AMPERAGE DRAW 28 Total Amps
MAXIMUM AIRFLOW 2,800 Total CFM
FITMENT
THIS PRODUCT IS UNIVERSAL
Radiator inlet and outlet locations intended for Chevy engine configuration
Dimensions with 31" radiator (HC9511D): 19" H x 31" W x 7" D
