Description
Mobil DTE 10 Excel Series are high performance anti-wear hydraulic oils specifically designed to meet the needs of modern, high pressure, industrial and mobile equipment hydraulic systems.
Passing results of acute aquatic toxicity testing (LC-50, OECD 203)
Applications
Industrial and mobile equipment hydraulic systems operating at high pressures and temperatures in
critical applications. Hydraulic systems subject to deposit build-up such as sophisticated Computer Numerically Controlled (CNC) machines, particularly where close clearance servo-valves are used. Systems where cold start-up and high operating temperatures are typical. Systems requiring a high degree of load-carrying capability and anti-wear protection. Machines employing a wide range of components using various metallurgy.
Specifications and Approvals
DIN 51524-2: 2006-09, DIN 51524-3: 2006-09, ISO 11158 L-HV, Voith VN108 4.3.3, HOCNF Norway/NEMS.
Mobil DTE 10 Excel Series has the following builder approvals:
Denison HF-0, Eaton Vickers 694 (encompasses former I-286-S, M-2950-S or M-2952-S), Fives Cincinnati P-69, ORTLINGHAUS-WERKE GMBH ON 9.2.10, STROMAG AG TM-000 327.
Typical Properties
ISO Viscosity Grade – 68
Viscosity, ASTM D 445
cSt @ 40deg C – 68.4
cSt @ 100deg C – 11.17
Viscosity Index, ASTM D 2270 -156
Brookfield Viscosity ASTM D 2983, cP @ -20 °C- 3990
Brookfield Viscosity ASTM D 2983, cP @ -30 °C – 16380
Brookfield Viscosity ASTM D 2983, cP @ -40 °C –
Tapered Roller Bearing (CEC L-45-A-99), % Viscosity Loss -11
Density 15deg C, ASTM D 4052, kg/L - 0.8626
Copper Strip Corrosion, ASTM D 130, 3 hrs @ 100deg C -1B
FZG Gear Test, DIN 51354, Fail Stage -12
Pour Point, degC, ASTM D 97 - -39
Flash Point, degC, ASTM D 92 -240
Foam Sequence I, II, III, ASTM D 892 , ml -20/0
Dielectric Strength, kV, ASTM D877 –
Acute Aquatic Toxicity (LC-50, OECD 203) – PASS
Passing results of acute aquatic toxicity testing (LC-50, OECD 203)
Applications
Industrial and mobile equipment hydraulic systems operating at high pressures and temperatures in
critical applications. Hydraulic systems subject to deposit build-up such as sophisticated Computer Numerically Controlled (CNC) machines, particularly where close clearance servo-valves are used. Systems where cold start-up and high operating temperatures are typical. Systems requiring a high degree of load-carrying capability and anti-wear protection. Machines employing a wide range of components using various metallurgy.
Specifications and Approvals
DIN 51524-2: 2006-09, DIN 51524-3: 2006-09, ISO 11158 L-HV, Voith VN108 4.3.3, HOCNF Norway/NEMS.
Mobil DTE 10 Excel Series has the following builder approvals:
Denison HF-0, Eaton Vickers 694 (encompasses former I-286-S, M-2950-S or M-2952-S), Fives Cincinnati P-69, ORTLINGHAUS-WERKE GMBH ON 9.2.10, STROMAG AG TM-000 327.
Typical Properties
ISO Viscosity Grade – 68
Viscosity, ASTM D 445
cSt @ 40deg C – 68.4
cSt @ 100deg C – 11.17
Viscosity Index, ASTM D 2270 -156
Brookfield Viscosity ASTM D 2983, cP @ -20 °C- 3990
Brookfield Viscosity ASTM D 2983, cP @ -30 °C – 16380
Brookfield Viscosity ASTM D 2983, cP @ -40 °C –
Tapered Roller Bearing (CEC L-45-A-99), % Viscosity Loss -11
Density 15deg C, ASTM D 4052, kg/L - 0.8626
Copper Strip Corrosion, ASTM D 130, 3 hrs @ 100deg C -1B
FZG Gear Test, DIN 51354, Fail Stage -12
Pour Point, degC, ASTM D 97 - -39
Flash Point, degC, ASTM D 92 -240
Foam Sequence I, II, III, ASTM D 892 , ml -20/0
Dielectric Strength, kV, ASTM D877 –
Acute Aquatic Toxicity (LC-50, OECD 203) – PASS
