Description
Uni-T is one of the leading Test & Measurement solutions provider in the world & a prestige test meter br& throughout Asia. They are well known for high quality & affordable test & measurement products.
Compared with traditional multimeters, UT195’s troubleshooting capability, resolution, & precision are improved to find issues related to motor drive, factory equipment maintenance, electrical distribution, & repair etc. It is exquisitely designed & easy to operate.
The UT195DS industrial multimeters troubleshooting capability, resolution, & precision are improved to find issues related to motor drive, factory equipment maintenance, electrical distribution & excellent. The UT195DS comes with LOZ & a dual display.
Features:
IP65 rating, 2m drop proof, CAT III 1000V, CAT IV 600V
Large 6000-count LCD screen
sampling rate
True RMS
ACV 750V 5kHz b&width
(AC+DC) or (AV+FREQ) & more, dual mode
Flashlight
Auto LCD backlight controlled by light sensor (can be turned off)
LoZ voltage test, for ghost voltage measurement
Motor phase sequence measurement with 2 probes
20A current measurement (max 30 seconds)
31 analog bar
Low pass filter, 1kHz 3dB attenuation
12 month warranty
Specifications
DC voltage (V) 1000V ±(0.5%+3)
AC+DC 750V ±(0.7%+3)
AC voltage (V) 600V ±(1.5%+4)
LoZ ACV 600V ±(2%+3)
DC current (A) 20A ±(0.8%+3)
AC current (A) 20A ±(1%+3)
Resistance (?) 60M? ±(0.8%+2)
Capacitance 60mF ±(3%+5)
Frequency 60Hz~40MHz ±(0.1%+4)
Duty cycle 0.1%~99.9% ±(2%+5)
Power 9V battery
LCD size 66mm x 51mm
Product color Red & grey
Product net weight 437g
Product size 195mm x 95 mm x 58mm
St&ard accessories Test probes, battery, carrying bag, English manual
