Description
3/8" Dr. Flex Ratchet Split-Beam Click Wrench - PRECISION Instruments #C2FR130N
Overcome many of the problems associated with micrometer-style click wrenches in abusive environments.
The wrench has few components, and all critical parts are welded together at assembly.
There is no need to “work in” a C series torque wrench before using it the first time.
Neither is it necessary to adjust to the lowest torque setting after use.
Setting the tool requires only fingertip force since the adjustment mechanism is not under load.
Extremely accurate within 4% of reading from 20% of full scale to full scale. Guaranteed against defect in workmanship and materials for 1 year from the date of delivery providing that they have been used according to instructions.
Setting torque on adjustable wrenches is fast and easy because there is no spring tension on the adjustment knob.
Torque setting locks on adjustable wrenches for repetitive applications.
The wrench length is designed to provide the leverage required for maximum torque applications. The length also provides the needed reach for those-hard-to-get-at places.
Made in U.S.A.
Specifications:
Torque range: 25-135Nm (18-100ft/lbs.)
Overall length: 17.5/8" (448mm)
Width: 1.3/16" (30.2mm)
Head height (without square): 9/16" (14.3mm)
Finish: Nickel/chrome
Graduations: 5Nm
Length: 17.5/8" (448mm)
Drive size: 3/8" flex ratchet
Weight: 0.67kg. (1.47lbs.)
