Description
Right and rear extension table for greater cutting capacity
Electric brake
RHS max. rip / LHS max. rip 630mm / 530mm
1,500W* motor for impressive cutting performance
On-tool storage for TCT saw blade, rip fence, mitre gauge
Main table: 620 x 610 mm
Sub table (right extension): 620 x 150 mm
Sub table (rear extension): 610 x 70 mm
Sub table (left extension): 620 x 200 mm
Included accessories
TCT Saw blade 260 x 30mm (B-10774), Rip fence, Mitre gauge (with vise), Push stick, 2 x Wrenches, Hex wrench and Triangular Plate
Specifications
Blade diameter 260mm (10-1/4")
- at 90° 93mm
- at 45° 64mm
- at 0° - 93mm
Bevel angle 0 - 45°
No load speed 4,300rpm
Overall dimensions 726mm
Net weight 34.8kg
Continuous rating input 1,500 W
Power supply cord 2.0m
Electric brake
RHS max. rip / LHS max. rip 630mm / 530mm
1,500W* motor for impressive cutting performance
On-tool storage for TCT saw blade, rip fence, mitre gauge
Main table: 620 x 610 mm
Sub table (right extension): 620 x 150 mm
Sub table (rear extension): 610 x 70 mm
Sub table (left extension): 620 x 200 mm
Included accessories
TCT Saw blade 260 x 30mm (B-10774), Rip fence, Mitre gauge (with vise), Push stick, 2 x Wrenches, Hex wrench and Triangular Plate
Specifications
Blade diameter 260mm (10-1/4")
- at 90° 93mm
- at 45° 64mm
- at 0° - 93mm
Bevel angle 0 - 45°
No load speed 4,300rpm
Overall dimensions 726mm
Net weight 34.8kg
Continuous rating input 1,500 W
Power supply cord 2.0m
